Retlux / Category / Light sources / LED / RLT 101

60cm LED tube
9 W, G13

RLT 101
Cool white, 900 lm, 4000K, T8
3d photo

Glass LED tube T8 with protective PET film

LED tubes feature long life and low energy consumption. That is why they are often used in places where there is a need to enlighten large premises for a long time. Such as in industrial buildings and warehouses, and also in shops and offices. Noise and blinking are reduced as much as possible. Glass LED tube T8 with protective PET film

Description

Glass LED tube T8 with protective PET film
Dimensions: 60 * 2.6 cm
Socket: G13
Power: 9W
Luminous flux: 900lm
Light color: 4000K
Beam angle: 240 °
LED chip: 45 x Sanan 2835
Operating voltage: AC220-240V
Lifetime: 25,000 h
Ra: >80
Part of the delivery is also a starter-fuse for replacing starter when remodeling older fixtures designated for CFL tubes.

Technical specs

Energy class
The energy class scale on energy labels for light sources has changed since September 1, 2021. You will no longer find energy class with "pluses" on our products, as the scale will now be at the lower end of the scale at the current state of technology. Our light sources are still keeping the same excellent energy efficiency, only the metrics have changed. To keep it simple, just stick to the fact, that the earlier the letter in the alphabet, the more energy efficient the product is.
F
Head type
The shape of the head determines the deflector shape design at the light source. This parameter is important because some luminaries have limited interior space. Also, the head shape determines whether the light will be directed into space or, conversely, more spot-focused.
T8
Socket thread
The socket or thread is the connecting part of the light source with the luminary. There are many types of sockets, but the most commonly used are those with Edison thread E14 and E27, then the bayonet GU10 and pin socket GU5.3 (MR16). Small bulbs use a G9 or G4 socket for a change.
G13
Voltage
The operating bulb voltage at which the bulb shows the specified luminous flux parameter. Conventional light sources are either designed for 230V mains voltage or are low-voltage (e.g. 12V)
220 - 240 V
Power input
Power input is a physical quantity that expresses the amount of energy consumed by an appliance per time unit. The smaller the value, the more economical the product, but also less powerful.
9 W
Economical equivalent
The economical equivalent is simply to compare the consumption of a light source with a conventional tungsten filament bulb with the same luminous flux.
15 W
Version
The parameter defines the light source design. It can be, for example, a miniature, compact or large power bulb.
Linear
Lifetime
The service life of modern light sources is many times higher compared with tungsten filament light sources. The value expresses the number of hours that the light source is able to emit without appreciable loss of luminous flux.
25000 h
Luminous flux
Luminous flux. It’s denoted by the letter Φ and the unit is lumen (lm). Indicates the light energy that the source emits in 1 second. Thus, it is a form of power. The higher the value, the more light the light source emits.
900 lm
Colour of light
Warm white, cold white, daytime white. This is a verbal indication of colour temperature (in professional terms, chromaticity temperature). Basically, it can be said that warm white has a light colour of yellow, cold white has a bright white light. Daylight white is already a slightly bluish light. The nomenclature may differ from brand to brand. For easy orientation, we mark our light sources with sun icons of the appropriate colour.
Cool white
Diameter
The parameter indicates the diameter of the light source in mm. An important thing, especially if the luminary has limited space inside or there is a limited diameter shade.
26 mm
Weight
169 g

Download

  • Information Sheet
  • Energy Label
